ATC Series Jacquard weaving machine For Decoration PP mat carpet FEATURES (ATC900 36" ATC1200 48" ATC1800 72" ATC2750 108" Mat width ) Machine rotation is faster than that of the previous model Weft PP Pipes are automatically fed by feed roll. In a jacquard system, PP pipes are selected by design cards , which makes it possible To weave variously designed PP mats. The operator can easily change the design by Replacing the design card. One worker can operate 4 to 6 jacquard weaving machines Models equipped with left and right 2-Color Feeders are available for weaving2 to 4 colored PP mats.

Automatic Thickness Adjustable Device This device is for feeding warp thread automatically from the warp beam. Mat length (thickness) is freely adjustable. Feeder for weft PP pipe Feeder capacity is 1.5 times larger than that of the previous model. Which makes it possible to place and stock more PP pipes in the hopper and also makes it very easy to insert pp pipes into the feeder.

Misfeed preventing mechanism (Sequence controller is used) in the event one weft pp pipe is not fed to the machine, this mechanism automatically prevents and removes the next coming pp pipe. Upper guide pipe for warp thread Upper and lower guide pipes are made of high quality stainless steel, thus eliminating the problem of rust. Cam Cam has been especially hardened to endure high speed rotation. Feed roll The feed roll rubber is made of hard urethane of sufficient durability. A special high quality bearing is used for the under roll.

380V 50HZ Narrow Warp yard mat weaving machine 1000mm

Model ATC900 MAX Tube Colors 4 Colors
PP Mat Width 900MM Yard Space 4.18 or 4.83MM
Main Weaving Motor 380V 50HZ 0.55kw Needles QTY 4.18mm 279pcs
Needles;4.83mm 250pcs Hook
Main Spindle RPM 100-130RPM Yard Sensor
Auto Stopper
V-Belt Size / Yard Warper 1 pc or 2pc or 3pcs
Switcher / Jacquard Loom 1 pc
PP Tube & Dia According to mat requirements Carlton Card
218*68.5mm with
12pcs*32rows Holes
PP Tube Feeding Motor 0.18kw Carlton Card Qty about 2 meter
Lenght/ 1050pcs Carlton Card
PP Tube Feeding
Motor RPM
1400RPM 180w Motor , and PP
Tube feeding speed
about 2400 times per minute
Productivity 8-10 meter Length per hour
P.P. Tube Holder 2X2PCS and 2PCS Tube
feeding motors
Machine Net Weight 1100KGS
Holder Place 2PCS on both sides PACKAGE SIZE 2.1*1.1*2.25M
Straw Feeding Inlet    NOTE:  The mat come out from
the back of machines
